Z + F

Cable Stripping and Crimping Machines

Universal and modular stripper-crimpers are electropneumatic or electric stripping and crimping machines that can process different wires, ferrules and contacts individually or on reels. The machine has been specially developed for use in which it is important to strip a cable and provide it with a contact or wire end ferrule in one work step. The Electropneumatic range of crimping and stripping machines are designed to handle Tri-Rated cables and ferrules with precision and efficiency. This range offers enhanced control and reliability, ensuring consistent results for high-quality electrical connections. Ideal for applications requiring stringent standards and durability, these machines simplify the crimping and stripping process, helping to improve productivity while reducing operator fatigue.
  • Effortless Precision
  • Versatile crimping options
  • Seamless workflow - streamlined processing of insulated Z+F ferrules
  • Electropneumatic range(UNIC) is expertly designed to handle Tri-Rated Cable and Ferrules
  • Tool-free operation and rapid cycle time

Selected variant

Available in several variants

Selected variant

Technical data

Crimping length 8 mm
Crimping range 0.5 - 2.5 mm²
Cycle time 1,5 s
Dimension (mm) 200x323x188 (WxDxH)
Infeed length 30 mm
Weight 11 kg

Accessories

Related products

Related

contaclip kds sr90
Product news

Every angle covered with 90 degree cable entry system

Engineers and technicians are seeking solutions that streamline assembly whilst maintaining high levels of protection and flexibility. KDS-SR90 angled screw frames and inlays bring a new level of efficiency to cable routing with a unique 90° entry design.

crouzet millenium slim on limited time discount
Product news

The smallest logic controller ever on limited time discount

The smallest logic controller by Crouzet is now 20% off for a limited time only! A powerhouse packed into just 17.5mm! Efficiency, adaptability, and seamless integration with free software.

11 questions to get the right signalling device with Auer Signal & OEM Automatic
Blog

11 questions to get the right signalling device – a whitepaper

Do you require signalling devices and beacons in your production process? Download our latest whitepaper!

bespoke solutions electricity meter control boxes
Case studies

Control Box Assembly for Industrial Electricity Metering - A case study

Here, our customer requires control boxes for electricity metering systems. We leveraged our expertise to deliver easy-to-install, ready-to-use assemblies. We look forward to creating more of these bespoke control boxes for our customer.

DC circuit protection PISA M and circuit breakers
Blog

Safeguard systems with DC circuit protection

This blog talks all things DC circuit protection including the key components: electronic circuit breakers, fuses and current monitoring devices. As well as how to choose the right protection.

IATECH, the industrial automation technology exhibition OEM automatic
Company news

Recap of IATECH

Did you get a chance to visit IATECH at The Leicester Marriott Hotel? We had over 33 exhibitors and 8 fantastic Tech Talks throughout the day, Read all about the day, here.

Parts Air pressure Crimping length Crimping length CL Crimping range Cycle time Dimension (mm) Infeed length Weight Price
8 mm
0.5 - 2.5 mm²
1,5 s
200x323x188 (WxDxH)
30 mm
11 kg
5,5 bar
8 mm
0.5 - 2.5 mm²
1,5 s
390x330x430
35 mm
23 kg
5,5 bar
8 | 10 mm
0.5 - 2.5 mm²
2 s
335x485x565
27 mm
22 kg
5,5 bar
8 mm
0.5 - 2.5 mm²
1,5 s
390x330x460
35 mm
31 kg
5,5 bar
6|8|10 mm
0.5 - 2.5 mm²
1,5 s
390x330x460
27 mm
31 kg
5,5 bar
0.5 - 2.5 mm²
1,5 s
470x420x425
28 mm
42 kg
5,5 bar
6 - 12 mm
0.5 - 2.5 mm²
1,5 s
470x420x425
28 mm
42 kg
5,5 bar
Tr: 8-18 Qu 8-12 mm
4 - 10 mm²
2,5 s
530x400x460
28 mm
42 kg
