SENSECA
Model Flex is a calorimetric flow sensor with analogue output signal and one switching point. It is equipped with LED indication and is simple to set via the magnetic tab.
| Accuracy | +/- 10% of the final value, but at least +/- 2 cm / s |
|---|---|
| Connection type | External thread, G 1/4 " |
| Electrical connection | Plug M12x1, 4-pole |
| Flow range max | 150 cm/s |
| Flow range min | 1 cm/s |
| Function | calorimetric |
| Hysteresis | 0.04 |
| IP class | IP67 |
| Load max | 100 mA |
| Material of body | Stainless steel 1.4305 |
| Material of wetted parts | Stainless steel 316Ti |
|---|---|
| Materials clips | PA6.6 |
| Power consumption | 100 mA |
| Pressure range max | 100 bar |
| Repeatability | 1 % |
| Signal outputs | 4-20 mA |
| Temperature of media to | 70 °C |
| Voltage dc max | 24 V |
Model Flex is a calorimetric flow sensor with analogue output signal and one switching point. It is equipped with LED indication and is simple to set via the magnetic tab.
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Connection type | Signal outputs | Price | ||
|---|---|---|---|---|---|
Art:
FLEX-F008HK028I
Copied
|
External thread, G 1/4 "
|
4-20 mA
|
| ||
|
Art:
FLEX-F015HK029I
Copied
|
External thread, G 1/2 "
|
4-20 mA
|
| ||
|
Art:
FLEX-F008HK028P
Copied
|
External thread, G 1/4 "
|
4-20 mA + PNP transistor output
|
| ||
|
Art:
FLEX-F015HK029P
Copied
|
External thread, G 1/2 "
|
4-20 mA + PNP transistor output
|
|
Select a variant in the list
