DEFINOX
The diaphragm valve allows retention free flow and keeps flow diameter constant. Pressure drops are minimised.
Specifications:
- DN 8 to DN 51
- Ergonomic plastic handle with visual opening indicator
- Leak indicator to signal diaphragm damage.
- Pneumatic actuator- easily removed and transformable, NO-NC-DE
- Optional stainless steel handle
- No risk of bacterial development due to the smooth body profile
- Physical barrier between the valve interior and external enviroment
| Certificate | A3 & 3.1 EN10204 |
|---|---|
| Connection type | Weld ends |
| Description | Manual diaphragm valve |
| Design norm | SMS |
| Housing | Physical barrier between the valve interior and the external environment |
| Housing | PTFE |
| Inner diameter | 22,6 mm |
| Material of body | AISI 316 |
|---|---|
| Outer diameter | 25 mm |
| Pressure max | 8 bar |
| Surface finish | RA<0,8/1,2µm |
| Temperature range | -0°C/+140°C |
| Weight | 2,5 kg |
The diaphragm valve allows retention free flow and keeps flow diameter constant. Pressure drops are minimised.
Specifications:
- DN 8 to DN 51
- Ergonomic plastic handle with visual opening indicator
- Leak indicator to signal diaphragm damage.
- Pneumatic actuator- easily removed and transformable, NO-NC-DE
- Optional stainless steel handle
- No risk of bacterial development due to the smooth body profile
- Physical barrier between the valve interior and external enviroment
.jpeg?as=1&iar=0&hash=C35BE4FB444DCD3D5B98C5DBA7502AEA)
This blog post demonstrates 7 strong reasons production plants choose the HYGHSPIN twin screw pump by Jung Process Systems
When selecting a SUCO mechanical pressure switch, it's essential to consider several key factors...
.jpeg?as=1&iar=0&hash=A3BFC175C33A8E0858884EF1A7B44582)
When it comes to solenoid valves, reliability and ease of maintenance are essential. That’s why our new Emerson, high flow solenoid valve is designed with unique features that streamline testing, commissioning, and ongoing operation.Â
Did you get a chance to visit IATECH at The Leicester Marriott Hotel? We had over 33 exhibitors and 8 fantastic Tech Talks throughout the day, Read all about the day, here.
Did you know that OEM Automatic has been successfully providing valve actuation solutions?
We are thrilled to announce the launch of IATECH, THe Industrial Automation Technology expo at Leicester Marriott Hotel on 23rd October. The ultimate platform for showcasing our extensive product range and broad business areas, featuring over 50 leading suppliers under one roof!
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Description | Design norm | Inner diameter | Outer diameter | Pressure max | Weight | Price | ||
|---|---|---|---|---|---|---|---|---|---|
Diaphragm valve DMX, Manual, 1", Stainless steel/PTFE
Art:
DE-HS025F11100
Copied
|
Manual diaphragm valve
|
SMS
|
22,6 mm
|
25 mm
|
8 bar
|
2,5 kg
|
| ||
Diaphragm valve DMAX, Pneumatic, 1", Stainless steel/PTFE
Art:
DE-HS025A11100
Copied
|
Pneumatic diapragm valve
|
SMS
|
22,6 mm
|
25 mm
|
8 bar
|
10 kg
|
| ||
|
Diaphragm valve DMX, Manual, 1½", Stainless steel/PTFE
Art:
DE-HS038F11100
Copied
|
Manual diaphragm valve
|
SMS
|
35,6 mm
|
38 mm
|
8 bar
|
4,8 kg
|
| ||
|
Diaphragm valve DMAX, Pneumatic, 1½", Stainless steel/PTFE
Art:
DE-HS038A11100
Copied
|
Pneumatic diaphragm valve
|
SMS
|
35,6 mm
|
38 mm
|
8 bar
|
16,1 kg
|
| ||
|
Diaphragm valve DMX, Manual, 2", Stainless steel/PTFE
Art:
DE-HS051F11100
Copied
|
Manual diaphragm valve
|
SMS
|
48,5 mm
|
51 mm
|
8 bar
|
4,9 kg
|
| ||
|
Diaphragm valve DMAX, Pneumatic, 2", Stainless steel/PTFE
Art:
DE-HS051A11100
Copied
|
Pneumatic diaphragm valve
|
SMS
|
48,5 mm
|
51 mm
|
10 bar
|
16,2 kg
|
| ||
|
Diaphragm vavle DMX, Manual, DN10, Stainless steel/PTFE
Art:
DE-HD010F11100
Copied
|
Manual diaphragm valve
|
DIN
|
10 mm
|
12 mm
|
8 bar
|
0,5 kg
|
| ||
|
Diaphragm valve DMX, Pneumatic, DN10, Stainless steel/PTFE
Art:
DE-HD010A11100
Copied
|
Pneumatic diaphragm valve
|
DIN
|
10 mm
|
12 mm
|
8 bar
|
2,5 kg
|
| ||
|
Diaphragm valve DMX, Manual, DN15, Stainless steel/PTFE
Art:
DE-HD015F11100
Copied
|
Manual diaphragm valve
|
DIN
|
16 mm
|
18 mm
|
8 bar
|
0,6 kg
|
| ||
|
Diaphragm valve DMX, Pneumatic, DN15, Stainless steel/PTFE
Art:
DE-HD015A11100
Copied
|
Pneumatic diaphragm valve
|
DIN
|
16 mm
|
18 mm
|
8 bar
|
2,7 kg
|
| ||
|
Diaphragm valve DMX, Manual, DN25, Stainless steel/PTFE
Art:
DE-HD025F11100
Copied
|
Manual diaphragm valve
|
DIN
|
26 mm
|
29 mm
|
8 bar
|
2,4 kg
|
| ||
|
Diaphragm valve DMX, Pneumatic, DN25, Stainless steel/PTFE
Art:
DE-HD025A11100
Copied
|
Pneumatic diaphragm valve
|
DIN
|
26 mm
|
29 mm
|
8 bar
|
7 kg
|
| ||
|
Diaphragm valve DMX, Manual, DN40, Stainless steel/PTFE
Art:
DE-HD040F11100
Copied
|
Manual diaphragm valve
|
DIN
|
38 mm
|
41 mm
|
8 bar
|
4,5 kg
|
| ||
|
Diaphragm valve DMX, Pneumatic, DN40, Stainless steel/PTFE
Art:
DE-HD040A11100
Copied
|
Pneumatic diaphragm valve
|
DIN
|
38 mm
|
41 mm
|
8 bar
|
15,8 kg
|
| ||
|
Diaphragm valve DMX, Manual, DN50, Stainless steel/PTFE
Art:
DE-HD050F11100
Copied
|
Manual diaphragm valve
|
DIN
|
50 mm
|
53 mm
|
8 bar
|
4,8 kg
|
| ||
|
Diaphragm valve DMX, Pneumatic, DN50, Stainless steel/PTFE
Art:
DE-HD050A11100
Copied
|
Pneumatic diaphragm valve
|
DIN
|
50 mm
|
53 mm
|
8 bar
|
16 kg
|
|
Select a variant in the list
