ASCO - 2/2 Proportional valve 1/4"

  • Normally closed
  • Compact version
  • Working pressure 0 to 16 bar
  • Housing in brass or stainless

Selected variant

Available in several variants
ASCO_produktniva.tif

Save page as PDF

Technical data / Documents

Accessories & Related products

Selected variant

Technical data

General Data
Connection 1/4 BSP
Flow factor / flow coefficient 0,05
IP class IP65

Material Data
Material body Brass
Material seat Brass

Temperature Data
Temperature of media from -10 °C
Temperature of media to 90 °C

Additional Data
Pressure max 35 bar
Viscosity max 21 cSt
Weight 0,5 kg
Power consumption 8 W
Throughput 1,2 mm
Sensitivity <2%
Voltage dc 24 V
Temperature operational min -10 °C
Temperature operational max 75 °C
Material coil Epoxy
Differential air pressure max 16 bar
Differential pressure min 0 bar
Differential pressure vacuum max 1 bar
Flow max 0,8 l/min
Function 1 2/2
Function 2 Normally Closed (SPST)
Material plunger Stainless steel
Material glide ring PTFE
Material seat seal FPM
Material spring Stainless steel

Downloads

Measurements and connections

Accessories

Related

jungs process systems hyghspin
Blog

7 advantages of using HYGHSPIN twin screw pumps

This blog post demonstrates 7 strong reasons production plants choose the HYGHSPIN twin screw pump by Jung Process Systems

suco pressure switches
Blog

Select the pressure switch for you a step by step guide

When selecting a SUCO mechanical pressure switch, it's essential to consider several key factors...

emerson 327c
Product news Blog

Function test without opening the enclosure Emerson 327c

When it comes to solenoid valves, reliability and ease of maintenance are essential. That’s why our new Emerson, high flow solenoid valve is designed with unique features that streamline testing, commissioning, and ongoing operation.

IATECH, the industrial automation technology exhibition OEM automatic
Company news

Recap of IATECH

Did you get a chance to visit IATECH at The Leicester Marriott Hotel? We had over 33 exhibitors and 8 fantastic Tech Talks throughout the day, Read all about the day, here.

Valve actuation OEM automatic
Product news Company news

Our Valve Actuation Service

Did you know that OEM Automatic has been successfully providing valve actuation solutions?

IATECH industrial automation components exhibition in at leicester marriott hotel by OEM Automatic
Company news

OEM introduces IATECH - The Industrial Automation Technology Expo

We are thrilled to announce the launch of IATECH, THe Industrial Automation Technology expo at Leicester Marriott Hotel on 23rd October. The ultimate platform for showcasing our extensive product range and broad business areas, featuring over 50 leading suppliers under one roof!

Parts Connection Flow factor / flow coefficient Material body Material seat Weight Throughput Differential air pressure max Flow max Price
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC"
Art:
SCG202A001VS3 Copied
1/4 BSP
0,05
Brass
Brass
0,5 kg
1,2 mm
16 bar
0,8 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCG202A002VS3 Copied
1/4 BSP
0,12
Brass
Brass
0,5 kg
2,4 mm
8 bar
2 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCG202A003VS3 Copied
1/4 BSP
0,24
Brass
Brass
0,5 kg
3,2 mm
4 bar
4 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCG202A004VS3 Copied
1/4 BSP
0,42
Brass
Brass
0,5 kg
4 mm
2,5 bar
7 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCG202A006VS3 Copied
1/4 BSP
0,72
Brass
Brass
0,5 kg
5,6 mm
1,4 bar
12 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCG202A007VS3 Copied
1/4 BSP
0,9
Brass
Brass
0,5 kg
7,1 mm
1 bar
15 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCG202A051VS3 Copied
1/4 BSP
0,05
Brass
Brass
0,5 kg
1,2 mm
16 bar
0,8 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCG202A052VS3 Copied
1/4 BSP
0,12
Brass
Brass
0,5 kg
2,4 mm
8 bar
2 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCG202A053VS3 Copied
1/4 BSP
0,24
Brass
Brass
0,5 kg
3,2 mm
4 bar
4 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCG202A054VS3 Copied
1/4 BSP
0,42
Brass
Brass
0,5 kg
4 mm
2,5 bar
7 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCG202A056VS3 Copied
1/4 BSP
0,72
Brass
Brass
0,5 kg
5,6 mm
1,4 bar
12 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCG202A057VS3 Copied
1/4 BSP
0,9
Brass
Brass
0,5 kg
7,1 mm
1 bar
15 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A011VS3 Copied
1/4 NPT
0,05
Stainless steel 303
Stainless steel
0,6 kg
1,2 mm
16 bar
0,8 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A012VS3 Copied
1/4 NPT
0,12
Stainless steel 303
Stainless steel
0,6 kg
2,4 mm
8 bar
2 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A013VS3 Copied
1/4 NPT
0,24
Stainless steel 303
Stainless steel
0,6 kg
3,2 mm
4 bar
4 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A014VS3 Copied
1/4 NPT
0,42
Stainless steel 303
Stainless steel
0,6 kg
4 mm
2,5 bar
7 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A016VS3 Copied
1/4 NPT
0,72
Stainless steel 303
Stainless steel
0,6 kg
5,6 mm
1,4 bar
12 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A017VS3 Copied
1/4 NPT
0,9
Stainless steel 303
Stainless steel
0,6 kg
7,1 mm
1 bar
15 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A061VS3 Copied
1/4 NPT
0,05
Stainless steel 303
Stainless steel
0,6 kg
1,2 mm
16 bar
0,8 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A062VS3 Copied
1/4 NPT
0,12
Stainless steel 303
Stainless steel
0,6 kg
2,4 mm
8 bar
2 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A063VS3 Copied
1/4 NPT
0,24
Stainless steel 303
Stainless steel
0,6 kg
3,2 mm
4 bar
4 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A064VS3 Copied
1/4 NPT
0,42
Stainless steel 303
Stainless steel
0,6 kg
4 mm
2,5 bar
7 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A066VS3 Copied
1/4 NPT
0,72
Stainless steel 303
Stainless steel
0,6 kg
5,6 mm
1,4 bar
12 l/min
2/2 proportionality valve 1/4"
Proportional valve 2/2 NC 1/4" 24VDC
Art:
SCB202A067VS3 Copied
1/4 NPT
0,9
Stainless steel 303
Stainless steel
0,6 kg
7,1 mm
1 bar
15 l/min
