| Approvals | CE, cULus, TÜV |
|---|---|
| Cable length max | 70 m |
| Contact current max | 0,5 A |
| DC | 99 % |
| Disconnection | 12 ms |
| Exit time coded light | 19 |
| In compliance with | EMC, LVD, MD |
| IP class | IP65 |
| Material of body | Aluminium |
| MTTFd | 338 year(s) |
| Number of beams | 2 |
| PL | e (EN ISO 13849-1) |
| Protection field | 500 mm |
|---|---|
| Range | 0,5-30 m |
| Resolution | 519,75 |
| SIL | 3 (EN IEC 62061) |
| Storage temperature max | 70 °C |
| Storage temperature min | -25 °C |
| T1 (Life time in years) | 20 |
| Temperature operational max | 55 °C |
| Temperature operational min | -10 °C |
| Voltage tolerance | ±20 % |
Optimise your production line with encoders, inclinometers, displays and slip rings
Designed for high-performance safety applications such as material handling, conveyors, robotics, and system integration. OEM Automatic is excited to announce its latest supplier partnership with Hokuyo
Engineers and technicians are seeking solutions that streamline assembly whilst maintaining high levels of protection and flexibility. KDS-SR90 angled screw frames and inlays bring a new level of efficiency to cable routing with a unique 90° entry design.
Here, our customer requires control boxes for electricity metering systems. We leveraged our expertise to deliver easy-to-install, ready-to-use assemblies. We look forward to creating more of these bespoke control boxes for our customer.
ATEX ensures that both equipment and work processes are designed to minimize these risks and create a safe working environment.
We’re thrilled to welcome Tony Maton, our new Sales Engineer at OEM Automatic! Tony brings a wealth of knowledge and expertise in industrial automation and machine safety
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Disconnection | Exit time coded light | Number of beams | Protection field | Range | Resolution | Price | ||
|---|---|---|---|---|---|---|---|---|---|
Art:
SG4-BSR2-050-OC
Copied
|
12 ms
|
19
|
2
|
500 mm
|
0,5-30 m
|
519,75
|
| ||
|
Art:
SG4-BSR3-080-OC
Copied
|
13 ms
|
22
|
3
|
800 mm
|
0,5-30 m
|
419,75
|
| ||
|
Art:
SG4-BSR4-090-OC
Copied
|
14 ms
|
25
|
4
|
900 mm
|
0,5-30 m
|
319,75
|
| ||
|
Art:
SG4-BSR4-120-OC
Copied
|
14 ms
|
25
|
4
|
1200 mm
|
0,5-30 m
|
419,75
|
| ||
|
Art:
SG4-BLR2-050-OC
Copied
|
12 ms
|
19
|
2
|
500 mm
|
6-60 m
|
519,75
|
| ||
|
Art:
SG4-BLR3-080-OC
Copied
|
13 ms
|
22
|
3
|
800 mm
|
6-60 m
|
419,75
|
| ||
|
Art:
SG4-BLR4-090-OC
Copied
|
14 ms
|
25
|
4
|
900 mm
|
6-60 m
|
319,75
|
| ||
|
Art:
SG4-BLR4-120-OC
Copied
|
14 ms
|
25
|
4
|
1200 mm
|
6-60 m
|
419,75
|
|
Select a variant in the list
