| Connection | W2 |
|---|---|
| Contact gap | 0,4 mm |
| Contact type | Changeover (SPDT) |
| Force of the return movement min | 1 N |
| Hysteresis max | 0,35 mm |
| IP class | IP40 |
| Operating force max | 3 N |
| Operating power total max | 4,5 N |
| Overtravel min | 1,1 mm |
| Permissible overvoltage max | 20 N |
|---|---|
| Rated current at 250 V ac | 16 A |
| Sleep max | 16,1 mm |
| Switching point | 14,7±0,4 mm |
| Temperature operational max | 125 °C |
| Temperature operational min | -60 °C |
| Thermal current at 250 V ac | 20 A |
Optimise your production line with encoders, inclinometers, displays and slip rings
Designed for high-performance safety applications such as material handling, conveyors, robotics, and system integration. OEM Automatic is excited to announce its latest supplier partnership with Hokuyo
Engineers and technicians are seeking solutions that streamline assembly whilst maintaining high levels of protection and flexibility. KDS-SR90 angled screw frames and inlays bring a new level of efficiency to cable routing with a unique 90° entry design.
Here, our customer requires control boxes for electricity metering systems. We leveraged our expertise to deliver easy-to-install, ready-to-use assemblies. We look forward to creating more of these bespoke control boxes for our customer.
ATEX ensures that both equipment and work processes are designed to minimize these risks and create a safe working environment.
We’re thrilled to welcome Tony Maton, our new Sales Engineer at OEM Automatic! Tony brings a wealth of knowledge and expertise in industrial automation and machine safety
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Connection | Force of the return movement min | Operating force max | Operating power total max | Overtravel min | Power min | Rated current at 250 V ac | Sleep max | Switching point | Temperature operational min | Thermal current at 250 V ac | Voltage min | Price | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
831611 C/O W2
Art:
83161102
Copied
|
W2
|
1 N
|
3 N
|
4,5 N
|
1,1 mm
|
|
16 A
|
16,1 mm
|
14,7±0,4 mm
|
-60 °C
|
20 A
|
|
| ||
|
Fonction I (changeoverTerm. W3. Hi re.f.
Art:
83161118
Copied
|
W3
|
1 N
|
3 N
|
4,5 N
|
1,1 mm
|
|
16 A
|
16,1 mm
|
14,7±0,4 mm
|
-60 °C
|
20 A
|
|
| ||
|
V3 MICROSWITCH C/O W3
Art:
83161338
Copied
|
W3
|
0,2 N
|
0,8 N
|
2 N
|
1,2 mm
|
|
16 A
|
16,2 mm
|
14,7±0,3 mm
|
-60 °C
|
20 A
|
|
| ||
|
831613 C/O W6A5*
Art:
83161304
Copied
|
W6A5
|
0,2 N
|
0,8 N
|
2 N
|
1,2 mm
|
|
16 A
|
16,2 mm
|
14,7±0,3 mm
|
-60 °C
|
20 A
|
|
| ||
|
MICRO SWITCH C/O W3
Art:
83161501
Copied
|
W3
|
0,05 N
|
0,25 N
|
0,4 N
|
1,1 mm
|
|
4 A
|
16,3 mm
|
14,7±0,4 mm
|
-40 °C
|
5 A
|
|
| ||
|
MICROSWITCH C/O W3
Art:
83161806
Copied
|
W3
|
0,2 N
|
0,8 N
|
2 N
|
1,2 mm
|
0,001 A
|
5 A
|
16,2 mm
|
14,7±0,3 mm
|
-60 °C
|
6 A
|
4 V
|
|
Select a variant in the list
