Valpes
The ER quarter-turn electric actuator range is available in Premier (IP65) and Plus (IP66) models from 10Nm to 100Nm.
Also in quarter-turn, the V Range (IP68) is available in torques up to 2500Nm.
On/off, positioning, failsafe and ATEX models are available across the Valpes quarter-turn range.
The MT multi-turn actuator provides IP68 solutions from 25Nm to 75Nm for rising and non-rising stem applications.
There is an extensive line of additional options to Valpes electric actuators including:
- complete aluminium housing
- marine coating
- third position stop
- Bluetooth connect, control and check systems via the AXMART app.
What makes Valpes stand out?
Valpes have high standards in R&D, manufacturing, testing and aftersales service.
They have complete control of product quality and performance.
All actuators are 100% tested before despatch to ensure electrical and mechanical conformity and are also inspected during the actuator assembly process.
Examples of products
Product Ranges
Actuation
Electric actuators designed to deliver precise control and reliable performance in fluid and automation systems. These actuators feature high torque output, robust materials for durability, and adjustable stroke lengths, with options for different pressures, voltages, and sizes, ensuring optimal functionality in applications requiring precise movement and control across diverse industrial environments.
ER premier series electric actuator
Quarter Turn
- IP65
- 20Nm to 100Nm
- Working temperature -10°C to +55°C
- Secured manual override
ER plus series electric actuator
Quarter Turn
- IP66
- 10Nm to 100Nm
- Working temperature -10°C to +55°C
- Failsafe Actuator
VR series electric actuator
Quarter Turn
- IP68
- 25Nm to 75Nm
- Working temperature -20°C to +70°C
- Failsafe Actuator
VRX series atex electric actuator
Quarter Turn
- IP68
- 25Nm to 75Nm
- Working temperature -20°C to +70°C
- Failsafe and ATEX rated Actuator
VS series electric actuator
Quarter Turn
- IP68
- 100Nm to 300Nm
- Working temperature -20°C to +70°C
- Failsafe Actuator
VSX series ATEX electric actuator
Quarter Turn
- IP68
- 100Nm to 300Nm
- Working temperature -20°C to +70°C
- Failsafe and ATEX rated Actuator
VT series electric actuator
Quarter Turn
- IP68
- 600Nm to 2400Nm
- Working temperature -20°C to +70°C
- Failsafe Actuator
VTX series ATEX electric actuator
Quarter Turn
- IP68
- 600Nm to 1000Nm
- Working temperature -20°C to +70°C
- Failsafe and ATEX rated Actuator
VT plus series electric actuator
Quarter Turn
- IP68
- 600Nm to 2400Nm
- Working temperature -20°C to +70°C
- Failsafe Actuator
MT series electric actuator
Multi Turn
- IP68
- 25Nm to 75Nm
- Working temperature -20°C to +70°C
- AXMART Bluetooth module - Battery Failsafe
Electrical Actuator Packages
Electric actuator packages, designed to provide reliable control for valve systems in various industrial applications. These packages feature high-torque, low-power consumption actuators, with options for different voltages and stroke lengths, ensuring precise operation in both on-off and modulating control applications, perfect for use in automation and fluid control systems.
Low voltage actuator with ball valve 25-64bar
Electrically actuated valve
- Size 3/8" to 3"
- IP66 rated protection
- Working pressure up to 64 bar
- Working temperature ‐20°C to +150°C
High voltage actuator with ball valve 25-64bar
Electrically actuated valve
- Size 3/8" to 3"
- IP66 rated protection
- Working pressure up to 64 bar
- Working temperature ‐20°C to +150°C
Low voltage actuator with ball valve 16bar
Electrically actuated valve
- Size 3/8" to 2"
- IP66 rated protection
- Working pressure up to 16 bar
- Working temperature ‐20°C to +150°C
High voltage actuator with ball valve 16bar
Electrically actuated valve
- Size 3/8" to 2"
- IP66 rated protection
- Working pressure up to 16 bar
- Working temperature ‐20°C to +150°C
2 way wafer ball valve with actuator
With Valpes ER electric actuator
- Size 1/2" to 3"
- IP66 rated protection
- Operated by a Valpes ER electric actuator
- available in sizes 1/2" to 3"
Flanged ball valve with actuator
With Valpes VSX electric actuator
- Size 1/2" to 4"
- IP68 rated protection
- Operated by a Valpes VSX electric actuator
- Available in sizes 1/2" to 4"
High Multi Voltage Actuator and 2 way ball valves
Stainless steel
- Size 3/8" to 4"
- IP66 rated protection
- Working pressure up to 1000 psi
- Working temperature -20°C to +200°C
Low Multi Voltage Actuator and 2 way ball valve
Stainless steel
- Size 3/8" or 4"
- IP66 rated protection
- Working pressure up to 1000 psi
- Working temperature -20°C to +200°C
High Multi Voltage Actuator and 3 way L Ported ball valve
Brass
- Size 3/8" to 2"
- IP66 rated protection
- Working pressure up to 16 bar
- Working temperature -20°C to +120°C
Low Multi Voltage Actuator and 3 way L Ported ball valve
Brass
- Size 3/8" to 2"
- IP66 rated protection
- Working pressure up to 16 bar
- Working temperature -20°C to +120°C
