WIKA
Examples of products
Wika Company Brochure:
Wika Company Video:
Wika company video - If you're seeing this message the video cannot be shown. To see the video accept cookies. Your cookie settings can be changed on https://www.oem.co.uk/contact-us/contact
Product Ranges
Load Pins
The Load Pins offered by Wika are advanced force measurement sensors designed to accurately measure forces and loads in various applications. These load pins are embedded within mechanical structures such as hinges, sheaves, and lifting points, providing precise force measurement without the need for external mounting. They feature integrated strain gauges for real-time force measurement, and are available in multiple configurations, including options with built-in wireless communication for remote monitoring.
Wika Heavy-Duty Load Pin F5308
Heavy Duty Force Transducer
- Force range 1-3000 kN
- Stainless steel IP67
- Accuracy 1 or 2%
- Amplified output signal, 4-20 mA or 0-10 V DC
- ATEX / SIL3 approved as an option
Wika Load Pin F5301
Thin-film technology
- Force range 5-200 kN
- Stainless steel / IP67
- Accuracy 1 or 2%
- Amplified output signal, 4-20 mA or 0-10 V DC
- ATEX / SIL3 approved options
Load Cells
Wika's Load Cells are precision instruments designed for accurate force and weight measurement in a wide range of industrial applications. These load cells utilise advanced strain gauge technology to provide reliable and precise load measurement, ensuring high accuracy in dynamic and static load conditions. Available in various configurations, including single-point, shear beam, and compression types. These load cells also feature scalable outputs, making them adaptable to different control systems and data acquisition setups.
Wika F3831 Shear Force Sensor
- Measurement ranges 0..500 kg - 0..10,000 kg
- Accuracy 0.03% Fnom
- 2.0 ± 0.02 mV/V
- IP67
Wika Hydraulic Load Cell F1102
Force Transducer for welding tongs
- Operates without power supply
- Pressure plate 20x55x36mm
- Accuracy ≤±1.6%
- Sensor body - Plastic
- Piston movement ≤0.5mm
Wika Hydraulic Ring Load Cell F1607/F6116
Ring Force Transducer
- Operates without power supply
- Enables bolt penetration
- Accuracy ≤±1.6%
- Stainless steel pressure plate and piston
- Piston movement ≤0.5mm
Wika Hydraulic Load Cell F1106/F115/F1135/F1145
Compression Force Transducer up to 850 kN
- Operates without power supply
- Handles oblique forces up to 3°
- Accuracy ≤±1.6%
- Stainless steel pressure plate and piston
- Piston movement ≤0.5mm
Bending Beams And Shear Beams
Wika's Bending Beams and Shear Beams are high-precision force measurement devices. These sensors are commonly used in load cells and force measurement systems, providing accurate and reliable measurements in both bending and shear stress scenarios. The bending beams are designed to measure forces applied along their length, while the shear beams are optimised for forces acting perpendicular to the beam.
